CNC drill chuck SK 40 - 2.5/16 - 95 403.15.16

Name: CNC drill chuck SK 40 - 2.5/16 - 95 403.15.16
Brand: Kemmler GmbH
SKU: 403.15.16
Availability: OutOfStock

Brand: Kemmler GmbH Product Code: 161626

All about product

Description

Specification

Reviews 0

Questions0

CNC drill chuck SK 40 - 2.5/16 - 95 403.15.16

Нет в наличии

0.0 грн.

ADINTMS:ISO 7388-1 (DIN 69871)

ADINTWS:CNC drill chuck

Balancing quality:G6.3 | 15,000 rpm

BD1:27.5

BD2:50

Delivery

Payment

CNC drill chuck SK 40 - 2.5/16 - 95 403.15.16

0.0 грн.

Description

ISO 7388-1 AD/AF [DIN 69871 AD/B]

Application:
For mounting tools with straight shanks.

All holders are made of forged steel
Specific, low warpage hardened
Surface hardened HRC 58~60
Hardening depth 0.8mm~0.9mm
Taper angle tolerance < AT 3 according to DIN 2080
Surface roughness Ra < 0.4 µm
Tensile strength in the core of min. 800 N/mm² according to DIN
All functional surfaces finely machined

Specifications

Характеристики

ADINTMS

ISO 7388-1 (DIN 69871)

ADINTWS

CNC drill chuck

Balancing quality

G6.3 | 15,000 rpm

BD1

27.5

BD2

CNSC

AD/AF (AD/B)

DCONWS

2.5 - 16

DCP

Yes

DCPS

D10/H4.5

DRVS

LPR

Runout

SK 40

Weight

1.65 kg
