Cutting insert Z22.5511.02 Whitworth pipe thread 11 thread/inch HC8620

Name: Cutting insert Z22.5511.02 Whitworth pipe thread 11 thread/inch HC8620
Brand: D%c3%9cMMEL
SKU: 2631070011
Availability: OutOfStock

Производитель: D%c3%9cMMEL Модель: 43090

Все о товаре

Описание

Характеристики

Отзывы 0

Вопросы0

Cutting insert Z22.5511.02 Whitworth pipe thread 11 thread/inch HC8620

Нет в наличии

0.0 грн.

Design:HC8620

Designation:Z22.5511.02

H:1.48 mm

Packaging unit:1

Pitch:11 (2.30) TPI

Доставка

Курьером по Киеву Доставим в день получения

Новой почтой в отделения и почтоматы

по тарифам перевозчика

Оплата

оплата по счету

Cutting insert Z22.5511.02 Whitworth pipe thread 11 thread/inch HC8620

0.0 грн.

Описание

Further tools for bore diameters 10 to 33 mm available on request
Tool system for machining drill holes MINI-MILL

Type ZH 22 from bore O 22 mm
Solid carbide inserts, quality grade HC 8620
Solid carbide milling cutter shank with internal coolant supply
Steel milling cutter shank with internal coolant supply
3-rib toothing
For machining grooves, circlip grooves, ISO metric threads, Whitworth pipe threads and full radius grooves, as well as for chamfering and deburring

Cutting inserts for Whitworth pipe threads, DIN ISO 228 (259) + 2999 full profile

Характеристики

Design

HC8620

Designation

Z22.5511.02

1.48 mm

Packaging unit

Pitch

11 (2.30) TPI

0.31 mm

5.85 mm
