NC machine reamer HSS-E sim. to DIN212D 3mm H7

Name: NC machine reamer HSS-E sim. to DIN212D 3mm H7
Brand: ATORN
SKU: 1610100030
Availability: OutOfStock

Производитель: ATORN Модель: 42837

Все о товаре

Описание

Характеристики

Отзывы 0

Вопросы0

NC machine reamer HSS-E sim. to DIN212D 3mm H7

Нет в наличии

0.0 грн.

Cantilever length:33 mm

Coating:uncoated

Coolant supply:External

Cutting data:Cutting angle information - yes

Cutting material:HSSE

Доставка

Курьером по Киеву Доставим в день получения

Новой почтой в отделения и почтоматы

по тарифам перевозчика

Оплата

оплата по счету

NC machine reamer HSS-E sim. to DIN212D 3mm H7

0.0 грн.

Описание

NC machine reamers

For H7 fit
Right-hand cutting
Cutting material: HSS-E
Straight shank without square end
Form D: spiral-fluted with offset shank
To ensure maximum true running accuracy for use in hydraulic expansion chucks and high-precision chucks, these reamers are delivered with even shank diameters suitable
for reaming through-holes and blind holes
Also available in TiN-coated version

single

Usage characteristics

aluminum < 8% Si
aluminum >= 8 % Si
brass long
brass short
bronze long
bronze short
cast iron GG/GTS
cast iron GGG
form
D
form
D
plastic
austenitic stainless steel
stainless steel ferrit./martens.
steel < 1000 N/mm2
steel < 1400 N/mm2
steel < 700 N/mm2
superalloys Fe/NiCo based < 30 HRC
superalloys Fe/NiCo based >= 30 HRc
titanium alloys

Характеристики

Feed f steel

0.1 mm/rev

Totally stainless steel suitability

Характеристики

Cantilever length

33 mm

Coating

uncoated

Coolant supply

External

Cutting data

Cutting angle information - yes

Cutting material

HSSE

3 mm

Diameter max.

2.8 mm

Diameter min.

20.0 mm

Diameter min./max.

20.0-2.8 mm

DIN

212

fitness hartl total

61 mm

15 mm

28 mm

Packaging unit

Suitability not total iron

Suitability titanium/nickel/super total

Surface

Uncoated

Tolerance of fit

Tolerance of shank diameter

Tool holding device

HA parallel shank

Twist angle

9° (left)

6 pc.
