No-go thread ring gauge DIN13 M8x0.5 6g

Name: No-go thread ring gauge DIN13 M8x0.5 6g
Brand: SARA
SKU: 5410530805
Availability: OutOfStock

Производитель: SARA Модель: 26889

Все о товаре

Описание

Характеристики

Отзывы 0

Вопросы0

Нет в наличии

0.0 грн.

Design:Reject

DIN:13

Packaging unit:1

Standard constructional dimensions DIN:1502

Thread type x nominal diameter x pitch:M8 x 0.5 mm

Доставка

Курьером по Киеву Доставим в день получения

Новой почтой в отделения и почтоматы

по тарифам перевозчика

Оплата

оплата по счету

No-go thread ring gauge DIN13 M8x0.5 6g

0.0 грн.

Описание

Thread ring gauges

For testing bolt threads
Wear-resistant gauge steel, aged and hardened
Outer diameter milled
Precision-ground thread
Tolerances and dimensions in accordance with DIN ISO 1502
Tolerance class 6 g
No-Go rings marked in red
Threaded gauges for other thread types eg trapezoid, pipe, BSF, UN, UNC, UNF, UNEF, NPTF, Pg, Edison screw thread and left-hand thread, as well as other dimensions and tolerance classes are available on request
If required, all thread gauges can be supplied with a calibration certificate or DKD calibration certificate in accordance with the test equipment monitoring guidelines set out in VDI/VDE/DGQ 2618

For right-hand ISO fine-pitch metric thread, DIN 13

Характеристики

Design

Reject

DIN

Packaging unit

Standard constructional dimensions DIN

1502

Thread type x nominal diameter x pitch

M8 x 0.5 mm
